Measurement Measurement instruments for different applications

We offer large range of measurement instruments for your specific requirements: Clamp meter, digital multimeter, earth ground tester, electrical testing tools, HVAC tools, installation tools, insulation testers, laser distsance meters, power analyzer, power quality tools, scope meter, thermal imager, thermometer, vibration tester.

Clamp Meters 321/322:

• Voltage DC: 0 - 600V
• Voltage AC: 0 - 600V
• Current AC: Voltage AC: 0 - 400A
• Resistance: 0 - 400Ω
• Operating Temperature: -10°C to +50°C
• Operating Altitude: 2,000 meters
• Safety Rating: IEC 1010-2-032, 600V CAT III
• Battery Life: 100 hours typical (2 AAA carbon zinc)
• Size: 190 x 63 x 35 mm
• Weight: 230 gr.

Digital Multimeter Fluke 87V:

• Voltage DC: 0 - 1000V
• Voltage AC: 0 - 1000V
• Current DC: 0 - 10A
• Current AC: Voltage AC: 0 - 10A
• Resistance: 0 - 50Ω
• Capacitance: 10nF - 9,999μF
• Frequency: 199.99 Hz - 199.99 kHz
• Operating Temperature: -20°C to +55°C
• Operating Altitude: 2,000 meters
• Safety Rating: CAT III 1000 V CAT IV 600 V
• Battery Life: 400 hours typical without backlight
• Size: 201 x 98 x 52 mm
• Weight: 355 gr.

Earth Ground Tester 1625:

RA 3-pole ground resistance measurement (IEC 1557-5):

• Measuring Voltage: Vm = 20/48 V ac
• Short Circuit Current: 250 mA ac
• Measure Frequency: 94, 105, 111, 128Hz
• Resolution: 0.001 Ω to 100 Ω
• Measuring Range: 0.001 Ω to 299.9 kΩ
• Intrinsic error: ± (2 % of reading + 2 d)
• Operating Error: ± (5 % of reading + 5 d)
• Operating Temperature: -10°C to +50°C
• Operating Altitude: 2,000 meters
• Safety Rating: CAT II, 300 V
• Display: 2999 Digit LCD – 7 segment liquid crystal display with special symbols and backlight
• Battery Life: Typical 3000 measurements (RE+RH ≤ 1 kΩ)
• Size: 133 x 187 x 250 mm
• Weight: 1,100 gr.

Multifunction Installation Tester Fluke 1653B

• AC Voltage Measurement: 0 - 500V
• Continuity Testing: 0 - 2000Ω
• Insulation Resistance Measurement Test Voltage: 50 - 100 - 250 - 500 - 1000V
• Insulation Resistance Measurement Range: 0 - 200MΩ
• Loop Impedance Measurement: 100 - 500 VAC (50/60 Hz)
• PFC, PSC Test: 0 - 25 kA
• RCD Testing: AC, G, S, A
• Earth Resistance Test: 0 - 200Ω
• Operating Temperature: -10°C to +40°C
• Safety Rating: EN 61010-I CAT III 500V, CAT IV 300V
• Size: 100 x 250 x 125 mm
• Weight: 1,170 gr.

Insulation Resistance Tester Fluke 1555

• Test Voltage: 0 - 10,000V
• Range: 200kΩ - 2TΩ
• Bar graph range: 0 to 1 TΩ
• Leakage current measurement: 1 nA to 2 mA
• Capacitance measurement: 0.01 uF to 15.00 μF
• Display: 75 mm x 105 mm
• Operating Temperature: -20°C to +50°C
• Safety Rating: CAT III 1000 V, CAT IV 600 V
• Size: 170 x 242 x 330 mm
• Weight: 3,600 gr.

High Precision Power Analyzer Norma 4000:

• Number of Phases: 1 to 3
• Display: Color, 5.7“ / 144 mm - 320 x 240 pixel
• Bandwidth: dc to 3MHz or dc to 10MHz depending on input module
• Basic Accuracy: 0.2%, 0.1% or 0.03% depending on input modules
• Voltage Input Range: 0.3 V to 1000 V
• Current Input Range: 0.03 mA to 20 A depending on input module
• Safety Rating: EN 61010-1 / 2nd Edition 1000 V CAT II (600V CAT III)
• Size: 150 x 237 x 315 mm
• Weight: 5,000 gr.

Three Phase Power Logger Fluke 1735:

• V-rms Wye Measurement: 57 V/66 V/110 V/120 V/127 V/220 V/230 V/240 V/260 V/277 V/347 V/380 V/400 V/417 V/480 V ac
• V-rms Delta Measurement: 100 V/115 V/190 V/208 V/220 V/380 V/400 V/415 V/450 V/480 V/600 V/660 V/690 V/720 V/830 V ac
• A-rms Measurement: 115 A/150 A/3000 A rms (at sine)
• Energy Measurement: kWh, KVAh, kVARh
• PF (Power Factor): 0.000 to 1.000
• Frequency Measurement: 46 Hz to 54 Hz and 56 Hz to 64 Hz
• Harmonics: To 50th harmonic (< 50 % of nom)
• Display: ¼ VGA Graphic Color transmissive displays 320 x 240 Pixel
• Safety Rating: IEC 61010-1 600 V CAT III, double or reinforced insulation, pollution degree 2
• Size: 240 x 180 x 110 mm
• Weight: 1,700 gr.

Thermal Image Ti50FT

• Temperature Measurement: -20 ˚C to 350 ˚C in 2 ranges
• Image Presentation: 5" large high-resolution digital display
• 54 mm lens Field of View (FOV): 9 º horizontal x 6 º vertical
• Spatial resolution (IFOV): 0.47 mrad
• Min focus distance: 0.6 m.
• Frequency Measurement: 46 Hz to 54 Hz and 56 Hz to 64 Hz
• Harmonics: To 50th harmonic (< 50 % of nom)
• Display: 5" large high-resolution digital display
• Weight: 1,950 gr.

In case of any inquiries, please contact us and we will propose you the suitable measurement instrument for your needs.
